Applied Cable Diameter : Ø3 ~ Ø10
Extruder Diameter : Ø60 ~ Ø90
Applied Material : PVC, HFPE, HFPVC, Urethane, Rubber + PVC
Line Speed : Max 600 MPM (Depends on Total Countered Length)
Single Auto Take Up : Ø300, Ø400 (Plastic Bobbin)
Arm Type Pay-Off : Bobbin - Ø1000 (Max)
Auto Coiler : OD - Ø450, ID - Ø200 H - 100mm (MAX) (Coil Type)
Arm Type Take-Up : Bobbin - Ø1200 (max)(Diameter Control, Pre-Heater, Spark Tester and Lump Detector will be included in every Industrial cable line.)

Industrial Cable is used to control or communicate between a machine and control panel.
It is used in a wide variety of industries such as: elevators or industrial robots. The important characteristic of an industrial cable is that it has to be soft, flexible, and non-stretchable. To achieve these characteristics the pay-off needs to be driven by a motor.
The materials used in these lines are soft PVC, HFPE, HFPVC, Urethane, or Rubber + PVC mixed.
Take-up can be changed from bobbins to coils depending on the customer's needs.
